비상 디젤 발전기 세트
  • 비상 디젤 발전기 세트비상 디젤 발전기 세트

비상 디젤 발전기 세트

고품질 비상 디젤 발전기 세트는 중국 제조업체 Gutai Machinery가 제공합니다. 비상 디젤 생성기 세트는 의료 기관, 데이터 센터, 공항, 기차역, 지하철역 및 기타 교통 허브와 같은 시나리오에서 널리 사용됩니다.

Gutai Machinery is a leading China emergency diesel generator set manufacturer. Emergency diesel generator set is one of the generator equipment. Emergency diesel generator set is mainly used to ensure reliable power supply of critical loads when the main and backup power supplies are all interrupted. These critical loads usually include particularly important loads and fire loads in the first-level loads.


In special places such as nuclear power plants, diesel generators are also used to provide safety-level emergency power to ensure the normal operation and safety of equipment. As well as fire-fighting equipment such as fire pumps and sprinkler pumps, as well as electrical equipment such as life pumps and elevators that require reliable power supply, all require power supply equipment.


Emergency diesel generator set is widely used in the following scenarios:

1. In medical facilities, the stability of power supply is directly related to the life safety of patients. Emergency diesel generator sets can start quickly when power is interrupted to ensure the normal operation of medical equipment.


2. Data centers are the hubs of information exchange in modern society. Once power is interrupted, huge losses will be caused. Emergency diesel generator set provides reliable power guarantee for data centers to prevent data loss and server damage.


3. Transportation hubs such as airports, railway stations, and subway stations have extremely high requirements for power supply. Emergency diesel generator sets can ensure the normal operation of transportation facilities and maintain traffic order at critical moments.

Model XGT-400 manufacturer Quanzhou Gutai Machinery Equipment Co., Ltd
Voltage recovery time ≤1S Steady state frequency regulation ≤1%
rated voltage 400V/230V Frequency stabilization time ≤3S
Rated frequency 50HZ Transient frequency adjustment rate ≤1%
Electric system three-phase four-wire system Volatility rate ≤1%
Rated current 720A Reference weight 2900Kg
Power factor 0.8 (lag) Rotational speed 1500r/min
Steady-state voltage regulation rate ≤±1% Reference external dimensions
(Length * Width * Height)
3250*1280*1750(mm)
Transient voltage regulation rate -15%~+18% Cooling method Boosting intercooling
Fuel grade (Standard) 0 # light diesel oil (regular)
Warm)
Noise (LP7M) Normal configuration ≤ 117dB (A)
2、 Technical parameters of diesel engine
Origin (brand) Shangchai Power manufacturer Shanghai Diesel Engine Co., Ltd
output power 495KW Model 6ETAA12.8-G310
Number of cylinders 6 Compression ratio 17.0:1
Piston aperture/piston stroke 130mm/161mm Start mode Electric start
Minimum fuel consumption rate ≤190g/kw.h Starting power supply DC 24V
Exhaust volume 12.8L Speed Control electronic speed control
fuel system PT pump direct injection Air intake system turbocharging
Diesel engine type 6-cylinder straight, 4-stroke Emission limits for pollutants
price
Non road country III
3、 Technical parameters of generator
Brand Xingutai Model XGTW-400-4(400KW)
Excitation method Brushless, excitation, self cooling protection grade IP22
Voltage regulation system AVR automatic voltage regulation Short term overcurrent 3-5 Ie not less than 5S
Insulation level H Overload capacity 1.5Ie not less than 2 minutes
Winding material All copper wire winding Phase number and connection method three-phase four-wire system
